IMPORTANT DATA
• Battery voltage - 14,4 V
• Planing width, max. - 82 mm
• Cutting depth - 0 – 1,6 mm

Part no. 06015A0471

Extremely lightweight and precise
• Fast and precise work progress due to continuously variable depth-of-cut setting up to 1.6 mm
• High surface quality due to ultra-sharp and durable TC reversible blades
• Light weight (only 2.5 kg) for comfortable work
• Motor brake for putting the tool down safely
• Quick blade changes for continuous work
• Wood chip clearance to left or right, as desired

COMPLETE WITH
• 2 x 3.0 Ah Li-Ion batteries - 2 607 336 234
• AL 1860 CV quick charger - 2 607 225 324
• L-BOXX 238 - 2 608 438 693
• L-BOXX inlay

TECHNICAL DATA
• No-load speed - 14.000 rpm
• Cutting depth - 0 – 1,6 mm
• Rebating depth - 0 – 8 mm
• Planing width, max. - 82 mm
• Weight incl. Battery - 2,5 kg
• Battery voltage - 14,4 V

NOISE/VIBRATION INFORMATION
Measured values determined according to EN 60745
Total vibration values (vector sum of three directions)
• Vibration emission value ah - 3.0 m/sē
• Uncertainty K - 1.5 m/sē
The A-rated noise level of the power tool is typically as follows: Sound pressure level 79 dB(A); Sound power level 90 dB(A). Uncertainty K= 3 dB.
