IMPORTANT DATA
• Saw blade diameter - 305 mm
• Mitre setting - 52 ° L / 60 ° R
• Incline setting - 47 ° L / 47 ° R

Part no. 0601B23660 (110V version) 0601B23670 (240V version)

Sawing like never before: extremely smooth with lasting precision
• Lasting precision due to innovative, maintenance-free and extremely robust guide arm
• Frictionless slide mechanism ensures very easy sawing without loss of power
• Accurate cuts and the highest cut quality due to integrated double line laser and Top Precision Best for Wood saw blade
• Efficient dust extraction due to optimised suction spouts
• All controls for mitre and bevel settings are situated on the front of the machine to make work more convenient
• Pull-out material supports integrated on the right and left with integrated length stop
• Integrated carrying handle for easy transport
• Compact slide mechanism enables space-saving positioning directly against the wall
• Powerful motor (2000 watts) offers sufficient power reserves for thick woods
• Groove-cutting function

COMPLETE WITH
• Collet - 1 609 B02 585
• Dust bag - 1 609 B02 595
• Insert plate - 1 609 B02 375
• Internal hexagon - 1 609 B00 256
• Saw blade 305 mm - 2 608 642 103

TECHNICAL DATA
• Cutting capacity, 0° - 104 x 341 mm
• Cutting capacity, 45° mitre - 104 x 240 mm
• Cutting capacity, 45° incline - 51 x 341 mm
• Mitre setting - 52 ° L / 60 ° R
• Incline setting - 47 ° L / 47 ° R
• Depth x length x height - 67 x 82 x 69 cm
• No-load speed - 3.800 rpm
• Saw blade diameter - 305 mm
• Saw blade bore - 30 mm
• Weight - 32,1 kg
• Rated power input - 2.000 W
• Linked products - System accessories-AC categories - 172481

NOISE/VIBRATION INFORMATION
Measured values determined according to EN 60745
Total vibration values (vector sum of three directions)
• Vibration emission value ah - 2.5 m/s²
• Uncertainty K - 1.5 m/s²
The A-rated noise level of the power tool is typically as follows: Sound pressure level 93 dB(A); Sound power level 106 dB(A). Uncertainty K= 3 dB.


PLEASE STIPULATE ON ORDER IF YOU REQUIRE 240V OR 110V MACHINE
