IMPORTANT DATA
• Saw blade diameter - 254 mm
• Mitre setting - 47 ° L / 47 ° R
• Incline setting - 47 ° L / 2 ° R

Part no. 0601B20260 (110V version) 0601B20270 (240V version)

Powerful and compact
• Powerful 2000-watt motor – for precise work in a wide variety of materials
• Very compact design, low weight (14.5 kg) and integrated handle for easy transport
• Extremely long lifetime due to robust construction and dust-resistant motor technology
• Efficient dust extraction due to optimised suction spout
• High stability due to integrated support and rubber feet
• Precise working due to detailed and clearly visible scale
• Easy bevel setting
• Startup electronics increase convenience

COMPLETE WITH
• Clamp - 1 609 B00 839
• Dust bag - 2 605 411 204
• Hexagon socket spanner - 1 609 B00 707
• Saw blade 254 x 30 mm - 2 608 640 438

TECHNICAL DATA
• Cutting capacity, 0° - 89 x 130 mm
• Cutting capacity, 45° mitre - 89 x 89 mm
• Cutting capacity, 45° incline - 58 x 120 mm
• Mitre setting - 47 ° L / 47 ° R
• Incline setting - 47 ° L / 2 ° R
• No-load speed - 4.500 rpm
• Saw blade diameter - 254 mm
• Saw blade bore - 30 mm
• Weight - 14,5 kg
• Rated power input - 2.000 W
• Linked products - System accessories-AC categories - 172481

NOISE/VIBRATION INFORMATION
Measured values determined according to EN 60745
The A-rated noise level of the power tool is typically as follows: Sound pressure level 93 dB(A); Sound power level 106 dB(A). Uncertainty K= 3 dB.


PLEASE STIPULATE ON ORDER IF YOU REQUIRE 240V OR 110V MACHINE
