Extremely robust lever and spring construction for the highest work loads Powerful 2000 W motor with starting current limitation for fast work progress User-friendly quick clamping mechanism with continuously...

IMPORTANT DATA
• Cutting disc diameter - 355 mm
• Cutting disc bore - 25,4 mm
• No-load speed - 3.500 rpm

Part no. 0601B17260 (110V version) 0601B17270 (240V version)

The robust tool for the toughest applications
• Extremely robust lever and spring construction for the highest work loads
• Powerful 2000 W motor with starting current limitation for fast work progress
• User-friendly quick clamping mechanism with continuously variable mitre angle setting up to 45°
• Tried-and-tested Bosch angle grinder motor provides superior product lifetime
• Vertical D-handle for ergonomic working
• Integrated handle for easy transport

TECHNICAL DATA
• Cutting capacity, rectangle - 180 x 85 mm
• Cutting capacity, square - 110 x 110 mm
• Cutting capacity, L-profile - 130 x 130 mm
• No-load speed - 3.500 rpm
• Cutting disc diameter - 355 mm
• Cutting disc bore - 25,4 mm
• Weight - 18,0 kg

NOISE/VIBRATION INFORMATION
Measured values determined according to EN 60745
Total vibration values (vector sum of three directions)
• Vibration emission value ah - 3.0 m/sē
• Uncertainty K - 1.5 m/sē
The A-rated noise level of the power tool is typically as follows: Sound pressure level 95 dB(A); Sound power level 108 dB(A). Uncertainty K= 3 dB.


PLEASE STIPULATE ON ORDER IF YOU REQUIRE 240V OR 110V MACHINE
