The impact wrenches from Bosch drive screws precisely – in series and individually. Thanks to their high torques, these impact wrenches therefore ensure fast work progress in vehicle assembly, shelf construction and other application ranges.

IMPORTANT DATA
• Rated power input - 920 W
• Screw diameter - max. M30
• Torque, max. (hard screwdriving applications) - 1.000 Nm

Part no. 0601435141 (110V only)

The powerful tool for large screwdriving applications
• For heavy screw joints on trucks, construction machinery, in commercial vehicle construction, in the petrochemical and other heavy industries
• Auxiliary handle with backing pad that can be fitted in two positions for better handling
• Hanging hook for attaching to a balancer
• V-groove impact mechanism with low recoil torque and long lifetime
• High impact performance with low weight
• Forward/reverse rotation for tightening and loosening
• Torsion bars (special accessory) guarantee adherence to desired torque
• Easy-to-change tools

COMPLETE WITH
• Auxiliary handle - 2 602 025 075
• Hanging hook (ET no. 3601310013)

TECHNICAL DATA
• Rated power input - 920 W
• Torque, max. (hard screwdriving applications) - 1.000 Nm
• Torque, max. (soft screwdriving applications) - 500 Nm
• Toolholder - 1" external square
• Rated speed - 860 rpm
• Weight - 7,3 kg
• Length - 431 mm
• Height - 436 mm

FUNCTIONS
• Forward/reverse rotation

NOISE/VIBRATION INFORMATION
Measured values determined according to EN 60745
Total vibration values (vector sum of three directions)
Tightening screws and nuts of maximum permitted size
• Vibration emission value ah - 4.0 m/sē
• Uncertainty K - 0.5 m/sē
The A-rated noise level of the power tool is typically as follows: Sound pressure level 100 dB(A); Sound power level 113 dB(A). Uncertainty K= 3 dB.
