The right bit – always at hand
Integrated cylinder – the rotating bit cylinder contains the 12 most important screwdriver bits. Innovative Bosch EasySelect – intuitive and easy-to-operate Select function for conveniently changing the different bits. Illuminated window enables individual bits to be selected quickly and easily.

Part no. 0 603 977 070

• No memory effect, no self-discharge: always ready for use thanks to lithium-ion technology
• Durable: up to 90 screws with one battery charge
• Compact design for the best handling and control during use
• PowerLight – your workpiece is always well lit and clearly visible thanks to the built-in LED
• Forward/reverse indicator and charge level indicator via LED
• Automatic spindle lock for manual tightening or loosening of screws
• Softgrip for a better and comfortable hold

COMPLETE WITH
• 5-hour charger (2 609 003 263)
• 12 standard screwdriver bits
• Plastic carrying case

TECHNICAL DATA
• Screw diameter up to 5 mm
• No-load speed 210 rpm
• Max. torque for soft/hard screwdriving applications 3,5 / 4,5 Nm
• Battery voltage 3,6 V
• Charging time 4 h
• Chucks - magnetic bit holder with hexagonal shank
• Machine weight 0,50 kg

FUNCTIONS
• 3.6 Volt
• Lithium-ion technology
• Application: screwdriving
• Softgrip
• Integrated work light
• Forward/reverse rotation
• Charge level indicator
• Forward/reverse indicator
• Bosch EasySelect

NOISE/VIBRATION INFORMATION
Measured values determined according to EN 60745
Total vibration values (vector sum of three directions)
• Vibration emission value ah 2,5 m/sē
• Uncertainty K 1,5 m/sē
The A-rated noise level of the power tool is typically as follows: Sound pressure level 70 dB(A); Sound power level 80 dB(A). Uncertainty K= 3 dB.
